Different Types of Probability Distribution (Characteristics & Examples)

What is distribution?

A distribution represent the possible values a random variable can take and how often they occur.

Mean – it represent the average value which is denoted by µ (Meu) and measured in seconds.

Variance – it represent how spread out the data is, denoted by σ2 (Sigma Square). It is pertinent to note that it cannot be measured in seconds square which make no sense,therefore, variance is measured by Standard Deviation which is the square root of variance √σ2 and has the same unit as means.

There are two kinds of data i.e. population data and sample data.

population data and sample data.

Population and Sample Data Notation:

Population and Sample Data Notation, mean, variance and standard deviation

The more overfilled the mid of the distribution, the more data falls within that interval as show in figure

more data falls within that interval
more data falls within that interval

The fewer data falls within the interval, the more spread the data is, as shown in figure

fewer data falls within the interval, the more spread the data is,
fewer data falls within the interval, the more spread the data is,

Notation of Distributions:

Y – Actual outcome

y – one of the possible outcomes

P(Y=y) – Probability distribution which is equal to p(y)

Types of Probability Distribution Characteristics, Examples, & Graph
Types of Probability Distribution Characteristics, Examples, & Graph

TYPES OF DISTRIBUTIONS

Two major kind of distributions based on the type of likely values for the variables are,

  1. Discrete Distributions
  2. Continuous Distributions

Discrete Distribution Vs Continuous Distribution

A comparison table showing difference between discrete distribution and continuous distribution is given here.

Discrete Distributions Continuous Distribution
Discrete distributions have finite number of different possible outcomes Continuous distributions have infinite many consecutive possible values
We can add up individual values to find out the probability of an interval We cannot add up individual values to find out the probability of an interval because there are many of them
Discrete distributions can be expressed with a graph, piece-wise function or table Continuous distributions can be expressed with a continuous function or graph
In discrete distributions, graph consists of bars lined up one after the other In continuous distributions, graph consists of a smooth curve
Expected values might not be achievable To calculate the chance of an interval, we required integrals

Notation Explanation:

Notation Explanation of probability distribution

Here, X is variable, ~ tilde, N is types of distribution and ( µ, σ2) are its characteristics.

1. DISCRETE DISTRIBUTIONS:

Discrete distributions have finite number of different possible outcomes.

Characteristics of Discrete Distribution

  • We can add up individual values to find out the probability of an interval
  • Discrete distributions can be expressed with a graph, piece-wise function or table
  • In discrete distributions, graph consists of bars lined up one after the other
  • Expected values might not be achievable
  • P(Y≤y) = P(Y < y + 1)

In graph, the discrete distributions looks like as,

Discrete Distribution graph representation
Discrete Distribution graph representation

Examples of Discrete Distributions:

  1. Bernoulli Distribution
  2. Binomial Distribution
  3. Uniform Distribution
  4. Poisson Distribution

1.1 Bernoulli Distribution

In Bernoulli distribution there is only one trial and only two possible outcomes i.e. success or failure. It is denoted by y ~Bern(p).

Characteristics of Bernoulli distributions

  • It consists of a single trial
  • Two possible outcomes
  • E(Y) = p
  • Var(Y) = p × (1 – p)

Examples and Uses:

  • Guessing a single True/False question.
  • It is mostly used when trying to find out what we expect to obtain a single trial of an experiment.
Bernoulli distributions graph
Bernoulli distributions graph

1.2 Binomial Distribution

A sequence of identical Bernoulli events is called Binomial and follows a Binomial distribution. It is denoted by Y ~B(n, p).

Characteristics of Binomial distribution

  • Over the n trials, it measures the frequency of occurrence of one of the possible result.
  • E(Y) = n × p
  • P(Y = y) = C(y, n) × py× (1 – p)n-y
  • Var(Y) = n × p × (1 – p)

Examples and Uses:

  • Simply determine, how many times we obtain a head if we flip a coin 10 times.
  • It is mostly used when we try to predict how likelihood an event occurs over a series of trials.
Binomial distribution graph
Binomial distribution graph

1.3 Uniform Distribution

In uniform distribution all the outcomes are equally likely. It is denoted by Y ~U(a, b). If the values are categorical, we simply indicate the number of categories, like Y ~U(a).

Characteristics of Uniform Distribution

  • In uniform distribution all the outcomes are equally likely.
  • In graph, all the bars are equally tall
  • The expected value and variance have no predictive power

Examples and Uses:

  • Result obtained after rolling a die
  • Due to its equality, it is mostly used in shuffling algorithms
Uniform distribution graph representation
Uniform distribution graph representation

1.4 Poisson Distribution

Poisson distribution is used to determine how likelihood a certain event occur over a given interval of time or distance. It is denoted by Y ~ Po( λ ).

Characteristics of poisson distribution

  • It measures the frequency over an interval of time or distance.
Poisson Distribution characteristics

Examples and Uses

  • It is used to determine how likelihood a certain event occur over a given interval of time or distance.
  • Mostly used in marketing analysis to find out whether more than average visits are out of the ordinary or otherwise.
Poisson distribution graph
Poisson distribution graph

2. CONTINUOUS DISTRIBUTIONS:

Continuous distributions have infinite many consecutive possible values.

Characteristics of Continuous Distributions

  • We cannot add up individual values to find out the probability of an interval because there are many of them
  • Continuous distributions can be expressed with a continuous function or graph
  • In continuous distributions, graph consists of a smooth curve
  • To calculate the chance of an interval, we required integrals
  • P(Y = y) = 0 for any distinct value y.
  • P(Y<y) = P(Y ≤ y)

Examples of Continuous Distributions

  1. Normal Distribution
  2. Chi-Squared Distribution
  3. Exponential Distribution
  4. Logistic Distribution
  5. Students’ T Distribution
The continuous distributions graph
The continuous distributions graph

2.1 Normal Distribution

It shows a distribution that most natural events follow. It is denoted by Y ~  (µ, σ2). The main characteristics of normal distribution are:

Characteristics of normal distribution

  • Graph obtained from normal distribution is bell-shaped curve, symmetric and has shrill tails.
  • 68% of all its all values should fall in the interval, i.e. (µ – σ , µ+ σ )
  • E(Y) = µ
  • Var(Y) = σ2

Examples and Uses

  • Normal distributions are mostly observed in the size of animals in the desert.
  • We can convert any normal distribution into a standard normal distribution. Normal distribution could be standardized to use the Z-table
Z-table

Where, σ ensures standard deviation is 1 and µ ensures mean is 0.

Normal Distribution graph representation
Normal Distribution graph representation

2.2 Chi-Squared Distribution

Chi-Squared distribution is frequently being used. It is mostly used to test wow of fit. It is denoted by Y ~ X2 (k).

Characteristics of Chi-Squared distribution

  • The graph obtained from Chi-Squared distribution is asymmetric and skewed to the right.
  • It is square of the t-distribution.
  • E(Y) = k
  • Var(Y) = 2k

Examples and Uses:

  • It is mostly used to test wow of fit.
  • It comprises a table of known values for its CDF called the x2 – table.
 Chi-Squared distribution graph
Chi-Squared distribution graph

2.3 Exponential Distribution

It is usually observed in events which considerably change early on.  It is denoted by Y ~ Exp(λ).

Characteristics of exponential distribution

  • Probability and Cumulative Distributed Functions (PDF & CDF) plateau after a certain point.
  • We do not have a table to known the values like the Normal or Chi-Squared Distributions, therefore, we mostly used natural logarithm to change the values of exponential distributions.
Characteristics of Exponential Distribution

Examples and Uses

  • It is mostly used with dynamically changing variables, such as online websites traffic.
Exponential Distribution Graph representation
Exponential Distribution Graph

2.4 Logistic Distribution

It is used to observe how continuous variable inputs can affect the probability of a binary result. It is denoted by Y ~ Logistic(µ, s).

Characteristics of logistic distribution

  • The Cumulative Distributed Function picks up when we reach values near the mean.
  • The lesser the scale parameter, the faster it reaches values close to 1.
characteristics of logical distribution

Examples and Uses

It is mostly used in sports to predict how a player’s or team’s feat can conclude the result of the match.

Logistic Distribution Graph representation
Logistic Distribution Graph representation

2.5 Students’ T Distribution

Students’ T Distribution or simply called T Distribution is used to estimate population limitation when the sample size is small and population variance is not known. It is denoted by Y~ t(k).

Characteristics of Students’ T Distribution

  • A small sample size estimation of a normal distribution
  • Its graph is symmetric and bell-shaped curve, however, it has large tails.

Examples and Uses

  • It is used in examination of a small sample data which usually follows a normal distribution.
 Students’ T Distribution Graph
Students’ T Distribution Graph

Download: Types of Probability Distribution pdf
